PVC PE XLPE Insulated Screened SWA Armored Fire Resistance Flame Proof Instrument Cable Control Cable
Standards:
Manufacture according to BS 5308, BS EN 50288-7,IEC 60502-1
Cable Structure:
Rated voltage: 300/500V, 600/1000V
Conductor: Copper wire /tinned-copper wire, Class1, Class2, Class5
Insulation: PVC /PE /XLPE
Cabling: Two or three cores stranded (Pair or Triple)
Individual shield (if required): Al-plastic tape with drain wire
Overall shield: Al-plastic tape with drain wire
Inner sheath (applicable if there is an armour layer): PVC/PE
Armour layer: Galvanized steel wire / Steel tape
Outer sheath: PVC/PE/LSHF
Other characteristics: Oil resistant, Flame retardant, Anti-corrosion, UV,etc.
Application:
These cables are designed to connect electrical instrument circuits and provide communication services in and around process plants (e.g. petrochemical industry etc.). Suitable fordirect burial applications.
Physical and Thermal Properties:
Conductor: Annealed copper solid Class 1 or plain copper stranded Class 2 or flexible soft stranded copper class 5
Voltage Rating: 300V/300v
Test Voltage:1200V
Temperature range During operation (fixed state): -30°C - +90°C
Temperature range During Installation (Mobile state): -5°C - +50°C
Minimum bending radius: 10 X Overall Diameter
Electrical Data:
|
Conductor
|
Insulation
|
Mutual Capacitance
|
|
Nominal Cross Section
|
Resistance
|
Resistance
|
|
at 20°C
|
at 20°C
|
|
|
|
|
|
max.
|
min.
|
max.
|
|
mm2
|
ohm/km
|
Mohm.km
|
pF/m
|
|
|
|
|
|
0.5
|
36.7
|
5000
|
115
|
|
0.75
|
25
|
5000
|
115
|
|
1
|
18.5
|
5000
|
115
|
|
1.5
|
12.3
|
5000
|
115
|
Cable Parameter:
|
No.x2 x Cross Section
|
Nominal Insulation Thickness
|
Nominal Outer Sheath Thickness
|
Nominal Overall Diameter
|
Approx. Weight
|
|
No.x2xmm2
|
mm
|
mm
|
mm
|
kg/km
|
|
0.5mm2, Multipair
|
|
2x2x0.5
|
0.35
|
0.9
|
8.7
|
84
|
|
4x2x0.5
|
0.35
|
1
|
10.2
|
120
|
|
5x2x0.5
|
0.35
|
1
|
11.2
|
145
|
|
6x2x0.5
|
0.35
|
1
|
12.1
|
171
|
|
8x2x0.5
|
0.35
|
1.1
|
13.1
|
212
|
|
10x2x0.5
|
0.35
|
1.2
|
15.1
|
266
|
|
12x2x0.5
|
0.35
|
1.2
|
15.7
|
287
|
|
16x2x0.5
|
0.35
|
1.2
|
17.8
|
387
|
|
20x2x0.5
|
0.35
|
1.3
|
19.7
|
463
|
|
24x2x0.5
|
0.35
|
1.4
|
21.5
|
554
|
|
0.75mm2, Multipair
|
|
2x2x0.75
|
0.38
|
1
|
9.7
|
101
|
|
3x2x0.75
|
0.38
|
1
|
11.2
|
152
|
|
4x2x0.75
|
0.38
|
1.1
|
12.5
|
177
|
|
5x2x0.75
|
0.38
|
1.1
|
13.6
|
224
|
|
8x2x0.75
|
0.38
|
1.1
|
14.4
|
269
|
|
10x2x0.75
|
0.38
|
1.2
|
16.6
|
335
|
|
12x2x0.75
|
0.38
|
1.2
|
17.4
|
376
|
|
16x2x0.75
|
0.38
|
1.3
|
19.8
|
485
|
|
20x2x0.75
|
0.38
|
1.4
|
22
|
589
|
|
24x2x0.75
|
0.38
|
1.5
|
24
|
713
|
|
1.0mm2, Multipair
|
|
2x2x1.0
|
0.4
|
1
|
10.4
|
117
|
|
3x2x1.0
|
0.4
|
1
|
12.1
|
174
|
|
4x2x1.0
|
0.4
|
1.1
|
13.5
|
220
|
|
5x2x1.0
|
0.4
|
1.1
|
14.7
|
257
|
|
8x2x1.0
|
0.4
|
1.2
|
15.8
|
324
|
|
10x2x1.0
|
0.4
|
1.2
|
18
|
403
|
|
12x2x1.0
|
0.4
|
1.3
|
19
|
456
|
|
16x2x1.0
|
0.4
|
1.3
|
21.5
|
603
|
|
20x2x1.0
|
0.4
|
1.4
|
23.9
|
721
|
|
24x2x1.0
|
0.4
|
1.5
|
26.1
|
866
|
|
1.5mm2, Multipair
|
|
2x2x1.5
|
0.45
|
1
|
11.8
|
158
|
|
3x2x1.5
|
0.45
|
1.1
|
13.9
|
243
|
|
4x2x1.5
|
0.45
|
1.2
|
15.5
|
290
|
|
5x2x1.5
|
0.45
|
1.2
|
16.9
|
358
|
|
8x2x1.5
|
0.45
|
1.3
|
18.2
|
447
|
|
10x2x1.5
|
0.45
|
1.4
|
21
|
550
|
|
12x2x1.5
|
0.45
|
1.4
|
21.9
|
625
|
|
16x2x1.5
|
0.45
|
1.5
|
25.1
|
831
|
|
20x2x1.5
|
0.45
|
1.6
|
27.8
|
1007
|
|
24x2x1.5
|
0.45
|
1.7
|
30.4
|
1223
|
