Private Label Low Voltage Fire Resistantance Alarm Rated Cate6 600V Sheath 2 Core Wire Suke Cable®
Private Label Low Voltage Fire Resistantance Alarm Rated Cate6 600V Sheath 2 Core Wire Suke Cable®
Private Label Low Voltage Fire Resistantance Alarm Rated Cate6 600V Sheath 2 Core Wire Suke Cable®
Private Label Low Voltage Fire Resistantance Alarm Rated Cate6 600V Sheath 2 Core Wire Suke Cable®
Private Label Low Voltage Fire Resistantance Alarm Rated Cate6 600V Sheath 2 Core Wire Suke Cable®

Private Label Low Voltage Fire Resistantance Alarm Rated Cate6 600V Sheath 2 Core Wire Suke Cable®

Private Label Low Voltage Fire Resistantance Alarm Rated Cate6 Sheath Wire Cable can maintain normal operation in a high temperature fire environment for a long time, mainly to maintain the basic functions of power system.

Brand : Suke Cable®

Conductor : Copper

Conductor Type : Stranded

Insulation Material : PVC

Sheath Material : PVC

MOQ : 100 Meters

Whatapp:0086 19942882089

Email: sukecable@fjkangke.com

Product Details

Application: Fire Resistant - Mains and Sub-Mains, Fire Alarm Systems, Essential Services

Construction:
1.    Conductor - Plain annealed class 5 flexible copper
2.    Fire Resistant layer - Mica Tape
3.    Insulation - Cross-linked low-smoke halogen-free polyolefin compound (X-HF-110)
4.    Filler - Flame retardant material
5.    Binder Tape - Low smoke halogen-free flame retardant tape
6.    Outer sheath - Cross-linked low-smoke halogen-free polyolefin compound (HFS-110-TP)


 Suke fire resistant alarm cable


Cross Section:
2 core: 1.5~400mm2
3 core: 1.5~400mm2
4 core: 1.5~400mm2
5 core: 1.5~400mm2
2 core + earth: 1.5~400mm2
3 core + earth: 1.5~400mm2
4 core + earth: 1.5~400mm2

Temperature characteristics:
Conductor operating temperature: -40ºC~110ºC
Min. temperatrue laying condition: 0ºC

Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min

Color:

Insulation:

2 core: Red, Black
3 core: Red, White, Blue
4 core: Red, White, Blue, Black
5 core: Red, White, Blue, Black, Y/G
2 core + earth: Red, Black, Y/G
3 core + earth: Red, White, Blue, Y/G
4 core + earth: Red, White, Blue, Black, Y/G


Sheath: Red or according to customer requirements

Standard:

Cable design: AS/NZS5000.1
Conductor: AS/NZS 1125
Fire resistant : AS/NZS3013 (WS52W)



Sizes can be produced as you required.



Size

Conductor Strands

Insulation Thickness

2x1.5mm2

 7/0.52mm

0.6mm

2x2.5mm2

7/0.68mm

0.7mm

2x1.5mm2+1.5mm2

7/0.52mm

0.6mm

2x2.5mm2+2.5mm2

7/0.68mm

0.7mm

2x4mm2+2.5mm2

7/0.85mm+7/0.68mm

0.8mm

2x6mm2+2.5mm2

7/1.04mm+7/0.68mm

0.8m



About us

Cable internet providers in China





We have alarms on extruding insulation andjacket, to keep 100% quality.

Founded in 1994, Fujian Suke Cable Technology Co., Ltd. Decades of wire and cable manufacturing experience enables us to be one of Top 20 cable manufacturers in China. Our products cover low/medium/extra high voltage power cable, submarine cable, control cable, instrumentation cable, building wire, flexible rubber cable, fire rated cable, renewable cable, solar cable, industrial cable, LAN cable, coaxial cable etc, a total of nearly 30 series with 4,000 types and more than 50,000 specifications for various fields within over 100 countries.



38

No. of R&D Staff: 38

10

No. of Production Lines:Above 10

7

Number of Foreign Trading Staff:7

130

130 technical staff

3

The company has 3 factories





Our workshops and certifications

Copper wire and cable manufacturers

custom cable maker factory

Suke OEM ODM cable industrial

Wire & Cable Production





Our company has three plants possessing 200 square kilometers and over 4500 employees with 130 technicians creating annual export revenue exceeding 150 Million USD.



Also, our company has passed ISO 9001, ISO 14001, ISO45001, OHSAS18001,etc certificatiom, and has got CCC,TLC, TUV, VDE, UL, CE, SAA, BS etc. certificates for our products.









FAQ

What is building wire?

Building wire is generally used in house fixed wiring. It is PVC insulated unsheathed electric wire. The onstruction is CU/PVC.

Conductor Structure of Power Cable

1. Conductors comply with IEC, AS/NZS and BSI standard requirements

2. The conductors of multi-core have different shapes. The single-core is circular. The shape of Multi-core cable with size up to and 35m2 can be circular, semicircular and fan-shaped, the conductor with size over and 50m2 are circular and semicircle.

3. A single core is allowed with size below 16m2. Conductor More than 25m2 are multi strands.
